Features
-
Standard size from 5" ~48.5"
-
Brightness design from 500~2500nits
-
RGB / LVDS inteface
-
Related parts solutions: LED driver board, AD board, system control kits, computing solutions, Easy chassis and mounting brackets
-
Customization design
| Size / Code | Backlight | Active area (mm) | Key Specifications | Remark: features | ||||||
| Brightness (nit) | Resolution | View angle (Deg) | Contrast ratio | Interface | NTSC | |||||
| 5" | VM05BQ | LED | 91.4x91.4 | 500 / 1000 | 480x480 | 140 / 120 | 500:1 | RGB | square format | |
| 13.9 | VM14BS | LED | 338x105 | 1000 / 1500 | 1280x398 | 170 / 160 | 1000:1 | LVDS | ||
| 15.9 | VM16BS | LED | 376x105 | 1000 / 1500 | 1280x512 | 170 / 160 | 1000:1 | LVDS | ||
| 19" | VM19BS | LED | 476x134 | 1000 | 1920x538 | 178 / 178 | 3000:1 | LVDS | ||
| 19" | VM19S1 | LED | 476x89.4 | 1000 / 1500 | 1920x360 | 178 / 178 | 1200:1 | LVDS | ||
| 23.1" | VM23S1 | LED | 585.6 x 48.2 | 500 | 158x1920 | 178 / 178 | 3000:1 | LVDS | 72 | |
| 28" | VM28B2 | LED | 698 x 131 | 2400 / 1200 / 600 | 1920x360 | 178 / 178 | 4000:1 | LVDS | HT LC | |
| 28.6" | VM28B6 | LED | 698 x 196 | 2000 / 1000 | 1920x540 | 178 / 178 | 4000:1 | LVDS | HT LC | |
| 29.4" | VM29B1 | LED | 698 x 258 | 2000 / 1000 | 1920x720 | 178 / 178 | 2000:1 | LVDS | HT LC | |
| 37" | VM37B1 | LED | 904 * 254 | 700 / 1100 / 2500 | 1920x540 | 178 / 178 | 4000:1 | LVDS | HT LC | |
| 43" | VM43BA | LED | 1040 x 260 | 700 / 1300 / 2500 | 1920x480 | 178 / 178 | 4000:1 | LVDS | HT LC | |
| 48" | VM48Q1 | LED | 1194x224 | 1000 / 2000 | 3840x720 | 178 / 178 | 1000:1 | VbyOne | 72 | |
| 48.5 | VM49BA | LED | 1209x226.8 | 1100 / 2500 | 1920x360 | 178 / 178 | 4000:1 | LVDS | HT LC | |
